Features
- IP67 communication body and IP68 316 stainless steel probe
- High accuracy and fast response
- Wireless transmission free wiring
- Built-in high-capacity Li-SOCI2 battery
- Long distance lora wireless transmission
- Superior performance and long-term stability
Technical Specifications
| Mounting | Horizontal Installation |
| Theory | Ultrasonic Measurement |
| Output | RS485 |
| Description | Soil Sensor |
| Humidity Range | 0 to 100% |
| Conductivity Range | 0 to 0.002 S/m (0 to 2000 μs/cm), 0 to 0.01 S/m (0 to 10000 μs/cm), 0 to 0.02 S/m (0 to 20000 μs/cm) |
| PH Range | 3 to 10 |
| Salt Range | 0 to 0.002 S/m (0 to 2000 μs/cm), 0 to 0.01 S/m (0 to 10000 μs/cm), 0 to 0.02 S/m (0 to 20000 μs/cm) |
| Nitrogen/Phosphorus/Potassium Range | 0 to 8.8 lbs/ton (0 to 1999 mg/kg) |
| Measurement Accuracy | ±0.2°℃; ±2%; ±2%; ±1; ±2%; ±3%(mg/kg) |
| Resolution | 0.18 °F (0.1 ℃); 0.1%; 0.0001 S/m (1μs/cm); 0.01; 0.0001 S/m (1μs/cm); 0.0022 lbs/ton (1 mg/kg) |
| Operating Temperature | -22 °F to 158 °F (-30 ℃ to 70 ℃) |
