Features
- Wake up tags for efficient communication
- Read ID numbers and specified data from tags
- Write data to tag storage areas
- Compatible with W26 and W34 interfaces
- Communicate with controllers or PCs, SDK provided
Technical Specifications
| Frequency | 902 MHz to 928 MHz frequency band or 865 MHz to 868 MHz |
| Protocol | ISO 18000-6C |
| Operation Mode | Fixed Frequency or FHSS or Software Programmable |
| RF Power Output Adjustable | Power Output Adjustable Range: 0.1 W to 1 W |
| Built- In Antenna Type | Built-in Circularly polarized antenna |
| Communication Ports | RS-232 or RS-485 or Weigand 26 bits or 32 bits |
| Communication Rates | Up to 57,600 bps and software programmable |
| Power Consumed | + 5 V DC, Average power of less than 2 W |
| Programmable Application Platform | 1) Allows Programmable Interface with host applications 2) Currently Supports Visual Basic or VC applications |
| Reading Range | 0 ft to 49.21 ft (0 m to 15 m) |
| Size | 10.04 in x 10.04 in x 1.65 in (255 mm x 255 mm x 42 mm) |
| Weight | 5.9 lb (2.7 kg) |
