Features
- Support wider channels, up to 320MHz channel
- Supports 4096QAM, further improving transmission efficiency
- Supports MLO (Multi-Link Operation) multi-link connection function, multi-frequency concurrent
- Supports 10Gbps fiber optic interface and network interface at the same time, giving full play to device performance
- Supports both PoE (802.3bt) power supply and DC power supply, making installation and deployment more convenient
Technical Specifications
| Power Consumption | ≤ 60 W |
| Rate | 10 Gbps |
| WAN | 10 G |
| SFP+ | 10 G |
| Radio | 4 x 4 2.4GHz + 2 x 2 5GHz + 2 x 2 6GHz |
| Chipset | BE880-5262 |
| Standard | IPQ9574+QCN5024+QCN6274+AQR113C+QCA8081 |
| Flash | Nor32 MB (reserved), Nand 128 MB |
| DDR4 | 512 MB × 2 |
| 2.4G Frequency | 2.4 GHz to 2.484 GHz |
| 2.4G Wi-Fi standard | 802.11b or g or n or ax |
| 5G Frequency | 5.1 G and 5.8 G |
| 5G Wi-Fi Standard | 802.11 a or n or ac or ax or be |
| 6G Frequency | 5.925 GHz to 7.125 GHz |
| 6G Wi-Fi Standard | 802.11be |
| End Users | 384 |
| 2.4G RF Power | ≤ 20 dBm ± 2 dBm |
| 5.8G RF Power | ≤ 19 dBm ± 2 dBm |
| Power supply | PoE 802.3bt, DC 2.0 54 V or 1 A |
| Temperature | Working: 14 °F to 104 °F (-10 °C to 40 °C) Storage: -40 °F to 158 °F (-40 °C to 70 °C) Humidity: 5%RH to 95% RH (Non-Condensing) |
| Size | 8.583 in x 1.811 in (21.8 cm x 4.6 cm) |
| Weight | 1.213 Ibs (0.55 kg) |
