Technical Specifications
| Type | Active decoder Reader for Motorcycle skiing go cart MTB race |
| Frequency | Two route 125 khz Activation Two route 2.4 G back |
| Peak Inventory Speed | Multi-tag 300 tags per second (depend on tag and antenna or application) |
| Read Range | Any range by your needs(adjustable) |
| Interface | Ethernet TCP or IP(RJ45) rs232 TTL uart (Serial port) RS485(optional) |
| Application | Cycling, running ,skiing, go karting, motocycling, car racing |
| Working Principle | Active reader, loop or mat antenna, power regulator, active chip |
| Read Range | 3.28 ft to 9.84 ft (1 m to 3 m) (depend on antenna or tag and application) |
| Read Tag | Multiple tag reading, 1 tag to 300 tags at the same time (depend on antenna or tag and application) |
| Interface (Connector) | RS322, TCP or IP Ethernet (RJ45) |
| Identify Speed | 124.27 mph (200 kmh) |
| Weight | 4.18 lb (1.9 kg) |
| Humidity | Less than 95 % (+ 77 °F (+ 25 ᵒC)) |
| Shell Material | Alumunium Alloy |
| Operating Temperature | – 4°F to + 131°F (- 20 ᵒC to + 55 ᵒC ) |
| Storage Temperature | – 4°F to + 185°F (- 20 ᵒC to + 85 ᵒC) |
| Power Consumption Standard | Working power miliwatt (mW) |
| Dimension | 9.05 in x 8.26 in x 1.06 in (230 mm x 210 mm x 27mm) |
