Technical Specifications
| Flash or DDR3 | SPI NOR 8MB or 512MB x 1 |
| 2.4G RF | QCN5022 to 2.4G external FEM |
| 5.8G RF | QCN5052 to 5.8G external FEM |
| 2.4G Frequency | 2.4GHz to 2.484GHz |
| 2.4G Protocol | 802.11 b or g or n or ax |
| 5G Frequency | 5.150GHz to 5.850GHz |
| 5G Protocol | 802.11 a or n or ac or ax |
| Antenna | 4 x 2.4G or 5.8G dual band: 6 dBi |
| Data Rate | 2.4G 574Mbps MIMO 2 x 2, 5G 2402Mbps MIMO 2 x 2 |
| Power Consumption | ≤ 24 W |
| Data Rate | 1800 Mbps |
| DDR3L | 512MB |
| Frequency Range | 2.4GHz and 5.8GHz |
| End Users | 192+ |
| PPM | ±20ppm |
| PoE | 48 V (IEEE 802.3at) |
| Interface | 1 × 10 or 100 or 1000 RJ45 WAN Port 1 × Reset button, press 10 seconds to revert to default setting |
| 2.4G RF Power | ≤ 23 dBm |
| 5.8G RF Power | ≤ 23 dBm |
| Humidity | 5 %RH to 95 %RH non-condensing |
| Operating Temperature | -4 °F to 113 °F (-20 °C to 45 ℃) |
| Limit working temperature | 86 °F to 158 °F (30 °C to 70 °C) |
| Storage Temperature | 32 °F to 158 °F (0 ℃ to 70 ℃) |
| Dimension | 0.79 in × 13.78 in (2 cm × 35 cm) |
| Size | 11.61 in x 9.09 in x 3.15 in (29.5 cm x 23.1 cm x 8.0 cm) |
| Weight | 7.72 Ibs (3.5 kg) |
