Features
- Circular or linear polarization
- Polyurethane material
- DC to ground lightning material
- CNC Aluminium Alloy or Nylon hinge material
Technical Specifications
| Frequency Range | Default 895 MHz to 935 MHz and Customizable |
| Gain | 6 dBi |
| Connector | BNC and RP TNC and TNC and Customizable |
| Cable | `50 to 5 |
| Polarization | Circular or linear |
| Antenna Quantity | 4 pcs |
| Material | Polyurethane |
| Horizontal Beam Width | 75 ° |
| Vertical Beam Width | 65 ° |
| Impedance | 50 Ω |
| VSWR | < 1.5 |
| Maximum Input Power | 2 W |
| Lightning Protection | DC to ground |
| Hinge Material | CNC Aluminium Alloy or Nylon |
| Antenna Cable Length | 6.56 ft and 9.84 ft and 13.12 ft and 16.4 ft (2 m and 3 m and 4 m and 5 m) |
| Working Temperature | – 22 °F to 158 °F (- 30 °C to 70 °C) |
| Dimensions | 19.69 in x 13.78 in x 0.71 in (500 mm x 350 mm x 18 mm) each Connectable |
| Gross Weight | 39.68 lb (18 kg) |
