Overview
Customizable UHF RFID reader: Supports various frequencies. EPC Gen2 protocol. Range up to 31.49 in (800 mm). Input: DC 12 V to 24 V.
Technical Specifications
| Working Frequency | 865 MHz to 868 MHz or 920 MHz to 925 MHz or 902 MHz to 928 MHz (custom-design for frequency band) |
| Air Protocol | EPC global Gen2 (ISO18000-6C) |
| Reading Distance | Up to 31.49 in (800 mm) (relate to tag and environment) |
| Input Voltage | DC 12 V to 24 V or 3 A |
| Peak Current | 60 mA (DC 12 V) |
| Material | ABS |
| Antenna | 3 dBi circularly polarized antenna (built-in) |
| RF Power | 0 dBm to 18 dBm (± 1 dBm) (adjustable) |
| Interfaces | 1, Plug & Play Keyboard Emulation [KB] Port 2, USB to serial port [Com] Port |
| Datasheet | SDK (download link) C#, Java, C++ |
| Humidity | 5 % to 90 % non-condensing (+ 25 °C) |
| Operating Temperature | – 40 °F to + 167 °F (- 40 ℃ to + 75 ℃) |
| Storage Temperature | – 40 °F to + 185 °F (- 40 ℃ to + 85 ℃) |
| Dimensions | 5.59 in x 3.35 in 0.79 in (142 mm x 85 mm x20 mm) |
| Net Weight | 4.65 oz (132 g) |
