Overview
Passive tag 125khzRFID reader and keyboard emulation in the first installation process will prompt the reader information
Technical Specifications
| Dimensions | 4.92 in X 1.77 in X 3.35 in (12.5 cm X 4.5 cm X 8.5 cm) |
| Frequency | 125 KHZ |
| Communication Speed | 106 Kbit / s |
| Baud Rate | 9600 Kbit / s |
| Current Consumption | <100 MA |
| Interface | RS 232/R 232/USB |
| Full Support | TK4100, EM4200, EM4001, etc. Compatible format IC card (64bits, Manchester coding) |
| Expansion | I / O port free |
| Weight | 5.29 oz (0.15 kg) |
| Function | Identification, Collect Information |
| Power Supply | DC 5V |
| Data Transmission Mode | USB Interface |
| Maximum Operating Humidity | 0 % to 95 % relative humidity |
| Operating Temperature | 14 ºF to 158 ºF (-10 ºC to 70 ºC) |
| Storage Temperature | -4 ºF to 176 ºF (-20 ºC to 80 ºC) |
