Overview
The Inventory Master gigabit ethernet router integrating Routing / Switching / Security and other network application, configuring with 8 Of 10 / 100 / 1000 M Ethernet ports, 2 100 / 1000 M SFP optical ports, Supports direct docking with GPON OLT.
Features
- Secure Data Transfer
- Supports logging
- Supports port mirroring
- Supports version upgrade and rollback
- Supports ACL and NAT functions
Technical Specifications
| Fixed Port | 8 x 1000 M Ethernet Port 2 x 1000 M SFP Port 1 x Console port 1 x FUNC button 1 x USB Port 1 x Standard 3-Core Power Port |
| Power Consumption | ≤18 W |
| Power Input | DC 12 V 1.5 A |
| Housing | High-strength metal housing |
| IP Degree | IP 30 |
| Operating humidity | 10% RH to 95% RH |
| Operating temp. | -4 °F to 167 °F (-20 °C to 75 °C) |
| Storage Temp. | -40 °F to 185 °F (-40 °C to 85 °C) |
| GPON ONU | Support when the GPON optical module is inserted into the optical port |
| Mounting | Desktop wall-mounted DIN rail |
| Dimension | 10.67 in x 6.06 in x 1.30 in (27.1 cm x 15.4 cm x 3.3 cm) |
