Features
- Automatic scan Com Port or Network
- Support firmware upgrade
- Support Export Config or Import Config
- Multiple country languages
- Global frequency (860 MHz to 960 MHz)
- Password mode
- Read specify tag
- Relay
- Data cache (only TCP/IP communication: active mode support)
- Multiple customizable communication protocols
- Remote listening (only TCP/IP support)
- RSSI
Technical Specifications
| Frequency | 902 MHz to 928 MHz (US) or 865 MHz to 868 MHz (EU) |
| Protocol | EPC global UHF Class 1 Gen 2 or ISO 18000-6C |
| Built-In Antenna | 6 dbi circular antenna |
| Output Power Range | 0 dBm to 26 dBm (adjustable) |
| Read Range | 16.4 ft to 19.6 ft (5 m to 6 m) (depends on antenna, tag and application) |
| Work Mode | Active mode, trigger mode and answer mode (optional) |
| Interface | RS232 or 485 or USB or WG26 or RELAY or TCP or IP or POE or WIFI or 4G (optional) |
| Power Supply | 9 V to 36 V |
| Operating Temperature | 14 °F to 131 °F (-10 ℃ to +55 ℃) |
| Storage Temperature | -4 °F to 167 °F (-20 ℃ to +75 ℃) |
| Reader Size | 7.48 in x 7.48 in x 1.18 in (190 mm x 190 mm x 30 mm) |
| Net Weight | 1.65 lb (0.75 kg) |
