Technical Specifications
| Working Frequency | 902 MHz to 928 MHz or 865 MHz to 868MHZ |
| Standard | ISO18000-6B or ISO18000-6C to EPC Class1G2 |
| Interface | Wiegand26 or 34 or 42, RS485, RS232 (TCP or IP, WIFI and GPRS is customizable) |
| Power Supply | DC 7.5 V to 12 V,3 A |
| Development Kit | Provide SDK development kit, and C#, C++, Java routines |
| Antenna Power | 1 W (adjustable by software) |
| Input/Output Interface | 1 way trigger input or 2-way replay output (customized) |
| Ani-Thunder | 6000 V |
| Antenna | 8 dBi to 12 dBi circular polarization |
| Reading Range | 9.84 ft to 19.69 ft (3 m to 6 m) |
| Operating Temperature | -49 °F to 149 °F (-45 ℃ to 65 ℃) |
| Size | 8.66 in x 8.66 in x 1.57 in (220 mm x 220 mm x 40 mm) or 17.72 in x 17.72 in x 1.97 in (450 mm x 450 mm x 50 mm) |
| Weight | 4.41 lb to 11.02 lb (2 kg to 5 kg) |
