Technical Specifications
| Frequency | 902 MHz to 928 MHz 865 MHz to 868MHz (Adjustable) |
| Protocol | ISO18000-6C (GB) |
| Interfaces | Standard-WG, RS232 or 485, USB, TCP or IP |
| Baud Rate | 115200 bps |
| Work Principle | FHSS or Fixed Frequency |
| Work Mode | Timing or Active or Trigger |
| Antenna Gain | 8 dBi circular polarized antenna |
| RF Output Power | 0 dBm to 30 dBm (Adjustable) |
| Reading Distance | 0 m to 26.25 ft (8 m) or max 32.81 ft (10 m) (ISO standard white card tested by CPH) |
| Power Supply | + 9 V to + 25 V, > 2 A |
| Power Dissipation | < 3 W per hour |
| Work Tip | Buzzer |
| Working Humidity Range | 20 % to 95 % (No condensation) |
| Working Temperature Range | + 14 °F to +131 °F (- 10 ℃ to + 55 ℃) |
| Storage Temperature Range | – 4 °F to + 167 °F (- 20 % to + 75 ℃) |
| Dimension | 4.85 in x 4.85 in x 2.44 in (240 mm x 240 mm x 62 mm) |
| Weight | 2.87 lb (1.3 kg) |
