| Receiver | |
| Positioning Accuracy | ±5% of depth |
| Depth Measurement Accuracy | ±5% of depth (no adjacent pipeline interference) |
| Current Measurement Accuracy | ±5% of actual current |
| Depth Measurement Range | 0 ft to 19.68 ft (6 m) (A); 0 ft to 26.25 ft (8 m) (B); 0 ft to 32.81 ft (10 m) (C, D, E, H) |
| Working Modes | Valley mode, peak mode, broad peak mode, peak arrow mode |
| Working Frequencies | Radio, 50 Hz, 100 Hz (CPS), 512 Hz, 1 KHz, 2 KHz, 8 KHz, 33 KHz, 65 KHz, 83 KHz (varies by model) |
| Menu Setting | Chinese and English setting menu. |
| Working Temperature | -4 °F to 122 °F (-20 °C to 50 °C) |
| Battery | 7.4V lithium battery |
| Dimensions | 24.41 in × 11.81 in × 5.91 in (62 cm × 30 cm × 15 cm) |
| Weight | 5.07 lbs (2.3 kg, including battery) |
| Transmitter | |
| Output Power | 10 W |
| Working Frequencies | 128 Hz, 512 Hz, 1 KHz, 2 KHz, 8 KHz, 33 KHz, 65 KHz, 83 KHz |
| Working Modes | Direct connection, induction, and clamp (automatically converted) |
| Battery | 14.8 V built-in lithium battery pack |
| Working Temperature | -4 °F to 122 °F (-20 °C to 50 °C) |
| Dimensions | 13.7 in × 9.37 in × 4.72 in (34.8 cm × 23.8 cm × 12 cm). |
| Weight | 5.51 lbs (2.5 kg, including battery) |
