Features
- Cable continuity testing
- Port flash
- Cable length testing
- Cable length calibration
- Ping test for Ethernet testing
Technical specifications
| Cable Test Types | RJ45, RJ11, STP/UTP 5E, 6E network, telephone, coaxial cable |
| Max. Distance of Wiremap | 2000 m |
| Max. Distance of Length | 1000 m |
| Compatible Connectors | RJ11, RJ45, BNC, PING/PoE |
| Cable Map Indication | LCD (#1-#8) |
| Battery Type | 3.7 V lithium battery, 1800 mAh |
| Voltage Detector | Built into receiver (90-1000 V) |
| Work Temperature | 50 °F to 140 °F (10 °C to 60 °C) |
| Humidity | 32 °F to 158 °F (0 °C to 70 °C) |
| Dimension | Main Unit: 6.81 in x 3.62 in x 1.34 in (17.3 cm x 9.2 cm x 3.4 cm) Remote Unit: 4.17 in x 1.26 in x 1.18 in (10.6 cm x 3.2 cm x 3 cm) |
