Technical Specifications
| Shipping Term | TNT, DHL, FEDEX, EMS, UPS |
| Condition | Original Made Quality, Top Standard |
| Application | Industry |
| Display | Panel LED |
| Payment Term | Advance |
| Protocol Support | Standard/Special Protocol |
| Working Power | Rated voltage: 9-48 VDC |
| Power Consumption | <3 VA |
| Capacity Index (LAN) | 2 x 10/100M RJ45 interface |
| Serial Port | 2 x RS485 port + 1 x RS232 |
| Communication Master Station Protocols | <16/pc |
| Transmission Mode | Full or half duplex |
| Dual Machine Switching Time | <5s |
| MTBF | >50,000 hours |
| Status Indication | Panel LED, reflecting the serial port data transmission and reception status |
| Standard Protocol | IEC60870-5-101/103/104, MODBUS-TCP/IP, CDT, MQTT, etc. |
| Special Protocol | DNP3.0 and other over 30 protocols, can be developed according to on-site needs |
| EMC | Fast pulse group immunity, IEC61000-4-5, level 3, Surge immunity IEC61000-4-2, level 3, Electrostatic immunity IEC61000-4-4, level 3 |
| Working Environment | Ambient temperature: -13 °F to 158 °F (-25 °C to +70 °C), Relative humidity: 5% ~ 95%, no condensation |
| Storage Temperature | (-30 °C to +75 °C) -22 °F to 167 °F |
| Mounting Size | DIN rail mounted |
| Size (L×W×H) | 1.65 in x 5.39 in x 4.33 in (4.2 cm x 13.7 cm x 11 cm) (KPM202) |
