Features
- Smart Control in Palm
- Bluetooth Control Device
- Visual Fault Locator
- Dual Wavelength Test
Technical Specifications
| Optical Port Type | FC/PC (interchangeable SC, ST) |
| Data Interface | USB, mini-USB, 10M/100M Ethernet port |
| Loss Accuracy | 2.46 ft (0.75 m) + sampling interval + 0.005% × test distance) |
| Reflection Accuracy | ±0.05 dB/dB |
| Data Storage | ≥2000 |
| VFL Output | >5 mW |
| Light Source Output | >-5 dBm |
| Optical Power Meter | +26 dBm to -50 dBm (Replaceable: +6 dBm to -70 dBm) |
| Power Supply Mode | AC/DC adapter: AC: 100 V to 240 V, 50/60 Hz, 0.6 A; Lithium battery: 7.4 V, 6700 mAh, Li-ion |
| Operating Temperature | 23 ℉ to 122 ℉ (-5 °C to 50 °C) |
| Storage Temperature | -4 ℉ to 158 ℉ (-20 °C to 70 °C) |
| Relative Humidity | 0 % to 95% non-condensing |
| Volume | 8.93 in x 6.29 in x 2.75 in (22.7 cm x 16 cm x 7 cm) |
| Machine Weight | 24.25 lb (11 kg) |
