Overview
The Inventory Master’s high precision GPS 10-inch industrial rugged tablet IP67 is a field-ready industrial tablet engineered for fleet management, agriculture, transportation and other demanding outdoor applications. It combines a sunlight-readable 10.1-inch HD IPS display (1000 nits) with glove and rain touch modes and an octa-core processor to run mapping, telematics and data-capture software smoothly. High-precision GNSS positioning, fast 4G cellular data and dual-band Wi-Fi keep units connected on the move. The rugged IP67 enclosure and reinforced design resist dust, water immersion and drops, while the large removable 8000 mAh battery and optional warm-swap battery option extend uptime for long shifts. Extensive I/O (USB Type-C, USB 3.0 data, POGO docking, TF card and headphone jack) plus optional scanners, NFC and fingerprint support make integration with vehicle systems and back-office platforms straightforward. Designed for maintainability and field serviceability, it balances high performance with durable construction for industrial deployments.
Features
- Sunlight-readable 10.1-inch IPS display (1000 nits) with glove and rain touch support
- High-precision GNSS (GPS and GLONASS) for accurate outdoor positioning
- Rugged IP67 enclosure and drop-resistant design for harsh environments
- Octa-core performance with LTE, dual-band Wi-Fi and Bluetooth for reliable connectivity
- Removable 8000 mAh battery plus optional warm-swap battery configuration for extended uptime
- Rich I/O including USB Type-C (USB 3.0 data and OTG), POGO docking connector and TF card expansion
- Optional accessories: 1D and 2D scanner, NFC, fingerprint reader and docking station for custom solutions
- CAN bus data reading support for vehicle telematics and integration
Technical Specifications
| Display | 10.1-inch IPS, 1280 × 800 px resolution |
| Brightness | 1000 cd per m² (sunlight readable) |
| Touchscreen | Multi-touch capacitive; glove mode and rain mode |
| GPU | Adreno 506 (where specified) |
| Processor | Octa-core 1.8 GHz (Qualcomm Cortex-A53 or equivalent) |
| Operating System | Android 9.0 (primary) and Android 8.1 (alternate where noted) |
| RAM | 2 GB LPDDR3 (default); 4 GB optional |
| Internal Storage | 16 GB eMMC (default); 64 GB optional |
| Storage Expansion | Micro SD up to 128 GB |
| Front Camera | 5 MP (optional) |
| Rear Camera | 16 MP with LED light (optional) |
| Bluetooth | Bluetooth 4.2 BLE or Bluetooth 4.0 depending on variant |
| WLAN | IEEE 802.11 a and b and g and n and ac; 2.4 GHz and 5 GHz |
| Mobile Broadband | LTE and HSPA+ and UMTS and EDGE and GPRS and GSM (data and voice) |
| GNSS | GPS and GLONASS |
| NFC (optional) | Read and write modes, card emulation and peer-to-peer modes supported |
| Sound | Built-in speaker 2 W, 85 dB; internal microphones |
| Docking Connector | 1 × docking connector (POGO-PIN x24) |
| Headphone | 3.5 mm headphone jack and headset jack |
| USB | USB Type-C, compliant with USB 3.0 for data transfer; OTG support |
| Scanner (Optional) | 1D and 2D scanner support — PDF417, QR, Data Matrix and major barcode types |
| Fingerprint (Optional) | Capacitive area sensor (optional) |
| Sensors | Acceleration sensor, ambient light sensor, gyroscope, compass |
| CAN Bus | CAN 2.0b and SAE J1939 and OBD-II protocol support for vehicle data |
| Power Input | DC 8 to 36 V (vehicle power supported) |
| Battery (Standard) | 3.7 V, 8000 mAh Li-ion removable battery |
| Battery (Alternate) | User-replaceable 5000 mAh Li-ion with warm swap function (where specified) |
| Battery Charging Time | About 4.5 hours |
| Battery Operating Time | About 4.5 hours (typical) — runtime varies by workload |
| Audio/Video Formats | MP3, MP2, AMR, AWB, APE, M4A, MIDI, OGG, WAV, FLAC; MPEG4-SP, H.264, H.263, MP4, MKV, AVI, WEBM |
| Physical Design | Reinforced edges, removable battery bay for field maintenance |
| Drop Resistance | Drop resistance to approximately 3.93 ft/1.2 m (meets rugged device drop test parameters) |
| Vibration Resistance | Vibration resistant (industrial vibration profiles supported) |
| Dust Resistance | IP6x (dust-tight) |
| Water Resistance | IPx7 (immersion up to 3.2 ft/1 m for 30 minutes) |
| CAN Bus Protocols | CAN 2.0b and SAE J1939 and OBD-II |
| GPS Precision | High-precision positioning chip included |
| Audio Power | Built-in 2 W speaker |
| Charging Temperature | 32 °F to 131 °F (0 °C to 55 °C) |
| Storage Temperature | -4 °F to 158 °F (-20 °C to 70 °C) |
| Operating Temperature | 14 °F to 149 °F (-10 °C to 65 °C) |
| Dimensions (WxDxH) | 10.91 in × 7.28 in × 1.24 in (277 mm × 185 mm × 31.6 mm) |
| Weight (Product Only) | 2.99 lb (1357 g) |
