Features
- Touchscreen & Key Operation
- Built-in Fault Locator
- Long Battery Duration
- Intelligent Fault Analysis
Technical Specifications
| Type of Optical Fiber | Single mode |
| Center Wavelength | 1310 nm / 1550 nm (±20 nm) |
| Maximum Dynamic Range | 36 dB / 35 dB |
| Event Blind Zone | 4.9 ft (1.5 m) |
| Attenuation Blind Zone | 32.8 ft (10 m) |
| Display Type | 3.5-inch color LCD, touch screen operation |
| Optical Interface | FC/UPC (Interchangeable SC, ST) |
| Test Range | 1,640 ft (500 m), 3,281 ft (1 km), 6,562 ft (2 km), 13,123 ft (4 km), 26,247 ft (8 km), 32,808 ft (10 km), 52,493 ft (16 km), 104,987 ft (32 km), 209,973 ft (64 km), 419,947 ft (128 km) |
| Range Accuracy | ± (3.28 ft (1 m) + sampling interval + 0.005% × distance) |
| Attenuation Measurement | ±0.05 dB/dB |
| Reflection Measurement | ±4 dB |
| Data Storage | ≥ 1,000 test curves |
| Communication Interface | USB |
| Battery Operation Time | ≥ 10 hours |
| Operating Temperature | 23°F to 122°F (-5°C to 50°C) |
| Storage Temperature | -4°F to 158°F (-20°C to 70°C) |
| Relative Humidity | 0 to 95%, no condensation |
| Weight | ≤ 2.2 lbs. (1 kg) |
| Dimensions | 8.19 in × 4.33 in × 2.20 in (20.8 cm × 11.0 cm × 5.6 cm) |
