| CPU | Broadcom BCM2711, Quad-core A72 (ARM v8) @ 1.5 GHz |
| Memory | 2GB (2GB/4GB/8GB optional) LPDDR4 |
| Flash | 8GB (16GB/32GB optional) eMMC |
| Ethernet | Gigabit ethernet x 2, (1-WAN + 1-LAN or 2-LAN Configurable) |
| Cellular | 4G LTE CAT4, 3G, 2G, NB-IoT, CAT-M1 |
| Wi-Fi | Dual-band 2.4 GHz/5 GHz 802.11b/g/n |
| Bluetooth | Supported |
| GPS | Cellular module built-in supported (Optional) |
| SIM | 1.8 V/3 V; Drawer-type nano card holder x 1 |
| USB | USB 2.0 x 2 for peripherals, USB-C x 1 for power supply and console |
| HDMI | HDMI 2.0 x 2, (Up to 4k p60 video & audio output) |
| Additional Drive | 1 x M.2 socket with 2280 NVME SSD support |
| 40 Pin Standard Raspberry Pi HAT | Connector (Adaptor line needed) |
| Power Supply | 5 V/3 A via Type-C port |
| Power Switch | Switch button for power on/off |
| Power Consumption | Less than 10 W (system) |
| Real-Time Clock (RTC) | Embedded RTC, power supply with supercapacitor (Optional) |
| Protection | IP30 |
| Housing | Aluminum Heatsink with ABS Body |
| Cooling | Fanless cooling |
| Ambient Humidity | 5 % to 95% (non-condensing) |
| EMC Index – Static Electricity | Level 3 |
| EMC Index – Radiated Electric Field | Level 3 |
| EMC Index – Surge | Level 3 |
| Certification | CE |
| OS | Optimized Raspbian with SDK / OpenWRT V21 |
| Configuration | GUI, WebUI, Local CLI, Remote configuration |
| Upgrade Operate | Local USB upgrade and remote upgrade (optional) |
| Timed Startup and Shutdown | Supported |
| Application Features | VPN, Route Control, Firewall, NAS, Media Player, Node-RED, Docker |
| Network Features | WWAN and WAN Failover, Load Balance, PPP, PPPoE, SNMP, TCP, UDP, MQTT, |
| ARP, QoS, SNTP, Telnet, SSH |
| Ambient Temperature | -4 °F to 158 °F (-20 °C to 70 °C) |
| Storage Temperature | -22 °F to 165 °F (-30 °C to 75 °C) |
| Dimensions | 3.85 in x 3.85 in x 1.5 in (9.8 cm x 9.8 cm x 3.8 cm) |
