| Use | Industrial |
| Hard Drive Type | SSD + HDD |
| Video Memory Type | With the main memory |
| Processor Core | Quad Core |
| Operating System | Win 10 |
| Processor Type | Inter Core I5 |
| Graphics Card Chip Set | Integrated Card |
| HDD Rotation speed | SSD |
| Processor Series | Intel Core I5-8250U |
| Video Memory | 2GB |
| Video Card | Intel UHD Graphics 620 |
| After Sales Service | Return and Replacement |
| Plug Type | US, JP, CN, AU, UK, EU |
| Power | 52 W |
| RAM type | DDR4 |
| Mouse and keyboard | NO |
| Private Mold | Yes |
| CPU | Intel Core i5-8250U (6M Cache, 4 Cores 8 Threads, Base Frequency 1.60 GHz Turbo Frequency 3.40 GHz) |
| TDP | 15W |
| CPU Lithography | 14 nm |
| Memory Types | 2 X DDR4 SO-DIMM 260 pin |
| Memory Channels | Dual Channels |
| ECC Memory | Don’t Support |
| m.2 SSD | 1 X M.2 2280 M KEY PCIE3.0 |
| SATA | 1 X SATA 3.0 Slot for (6.3 cm) 2.5 in HDD or SSD |
| mSATA | 1 X mSATA slot |
| Processor Graphics | Intel UHD Graphics 620 |
| HD | 1 X HD 4096 X 2160 at 60 Hz(4K) |
| EDP | 1 X ED 4096 X 2160 at 60 Hz(4K) |
| DP | 1 X DP 4096 X 2160 at 60 Hz(4K) |
| Adapter Output | DC 12 V or 6 A |
| Adaptor Input | AC 110 V to 240 V, 50 HZ or 60 HZ |
| Consumption | 52 W |
| Auto Power on | Support Auto Power On Function |
| USB Port | 4 X USB 3.0 port,4 X USB 2.0 port |
| Audio | 1 X 0.1 in (3.5 mm) MIC in & SPK out |
| Video | HD 4096 X 2160 at 60 Hz + EDP 4096 X 2160 at 60 Hz + DP 4096 X 2160 at 60 Hz 3 Display Output |
| Audio Cards | Realtek ALC 662 or 897 |
| M.2 | 1 X M.2 E KEY 2230 |
| LPT | 1 X LPT(line print terminal) |
| WIFI | Inside Wifi & Bluetooth Combo |
| System | Support Windows 10 or 11, Linux |
| BIOS | Support TPM2.0,RAID,AUTO POWER ON, Wake On LAN, Watchdog, PXE or IPXE |
| SIM | 1 X SIM slot |
| MPCIE | 1 X MPCIE, Support 4G or Wifi module |
| Case Material | Full Brushed Aluminum Alloy |
| GPU | Intel UHD Graphics 620 |
| Max Memory Size | 64 GB |
| Com port | 6 X RS232 Com port |
| Display Port | HD + EDP + DP |
| USB Port | 4 X USB 3.0 port,4 X USB 2.0 port |
| LAN Port | 2 X RJ45 LAN Gigabit Ethernet Controller |
| Work environment | (-10 ℃ to 60 ℃) 14 °F to140 °F , 30 % to 90 % Humidity |
| Dimensions | 9.3 in X 7.1 in X 2.0 in (238 mm X 182 mm X 52 mm) |
| Weight | 3.3 lbs (1.5 kg) |
