Features
- Support PoE power supply or power adapter power supply
- Support IEEE 802.11n, IEEE 802.11g, IEEE 802.11b protocols
- Support Bluetooth® 4.2/ 5.0
- Support LTE-TDD/LTE-FDD/TD-SCDMA/UMTS / EVDO/EDGE/GPRS/GSM/CDMA
- One WAN/LAN adaptive port
Technical Specifications
| Power Supply | 12 V DC |
| Working Current | 2 80 mA 12 V (with 4 G module) 1 80mA 12V (without 4G module) |
| Protocol | LTE-TDD/LTE-FDD/TD-SCDMA/UMTS/ EVDO/EDGE/GPRS/GSM/CDMA |
| Receiver Sensitivity | -104 dBm |
| Scanning Distance | > 328.084 ft (> 100 m) |
| Connection Distance | 98.43 ft to 164.04 ft (30m to 50m) |
| Bluetooth Version | 4.2 or 5.0 |
| Wireless Protocol | 2.4 Ghz |
| Wireless Security | AES HW Encryption |
| Transmit Power | 0 to + 18 dBm |
| connection Distance | 98.42 ft to 164 ft (30 m to 50 m) |
| Input Power | AC 100 V to 240 V or 50 Hz to 60Hz) |
| Working Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Dimension | 4.13 in x 1.77 in x 1.77 in (105 mm x 45 mm x 45 mm) |
