Features
- Open Source OpenWrt system
- Managed by Web GUI, SSH via LAN or WiFi
- Emulates 49x LoRa demodulators
- SX1276 base seperate TX path
- 10 programmable parallel demodulation path
Technical Specifications
| Input Voltage | 12 V |
| Power Input | 1:00 AM |
| Communication Ports | 2 x 10M/100M RJ45 Ports |
| Wi-Fi | 1 x 2.4G WiFi (802.11 bgn) |
| USB Host Port | 1 |
| Mini-PCIe Interface | 1 |
| Frequency | 868 MHz or 915 MHz |
| GPS Module | Yes (for LoRa localization) |
| Surge Protection | 10 kV (L-N 4 kV; L/N-GND 6 kV) |
| Control Capacity | Max 49 LoRa demodulators |
| Weight | 0.88 lb (0.4 kg) |
| Working Temperature | -22 °F to 158 °F (-30 °C to 70 °C) |
| Size | 5.91 in x 4.72 in x 1.26 in (15 cm x 12 cm x 3.2 cm |
