Features
- Multi-frequency support: 433/868/915MHz
- Integrated Wi-Fi and LTE connectivity
- GPS for precise location tracking
- Reliable LoRaWAN outdoor access point
- Optimized for wireless meter reading
- Weatherproof design for outdoor use
- Low power consumption for efficiency
Technical Specifications
| CPU | Broadcom BCM2711, Quad-core A72 (ARM v8)@ 1.5 GHz |
| Memory | 2GB (2GB/4GB/8GB Optional) LPDDR4 |
| Flash | 8GB (16GB/32GB Optional) eMMC |
| Operating System | Raspbian/ElastOS |
| Interfaces | GbE/DI/DO/RS232/RS485 |
| Network | 4G LTE, 3G, 2G, NB-IoT, CAT-M1 |
| Wi-Fi | Dual-band 2.4GHz/5GHz 802.11b/g/n |
| GPS | Supported (Optional) |
| SIM | 15KV ESD Protection |
| Antenna | 4G: inside SMA x 1,WiFi/Buletooth: Inside SMa |
| Industrial Serial Port | RS-232 signal: TXD, RXD, GND; RS-485 Signal: A, B, GND; ESD Protection: 15KV |
| I/O | 2-channel Digital Input DI 2-channel Digital/Pulse Output DO |
| USB | USB 2.0 x 2 for Peripherals, USB-C x 1 for Power Supply and Console |
| HDMI | HDMI 2.0 x 1, (Up to 4kp60 Video & Audio Output |
| Additional Drive | 1 x M.2 Socket with 2280 NVME SSD Support |
| Power Terminal | Unpluggable Industrial Terminal Connection |
| Power Consumption | Less than 10 W (System) |
| (Optional) Real-Time Clock (RTC) | Embedded RTC, Power Supply with a Supercapacitor |
| Protection | IP30 |
| Housing | Aluminum Heatsink |
| Cooling | Fanless Cooling |
| Installation | DIN-rail, Wall Mounting |
| Storage Temperature | −22°F to 167°F (-30°C to 75°C) |
| Ambient Humidity | 5% to 95% (Non-condensing) |
| Operating Temperature | -13°F to 158°F (-25°C to 70°C) (Industrial Grade) |
| Dimensions | 4.88 in x 2.99 in x 1.38 in (12.4 cm x 7.6 cm x 3.5 cm) |
