Features
- Expert OTDR: Professional measurement, curve / list / map are displayed simultaneously
- Auto OTDR: no complex settings, one key test
- OPM supports CW / 270 / 330 / 1k / 2KHz frequency identification
- VFL and LS can run in the background, multitask can be operated simultaneously
- LS supports CW / modulation mode output with adjustable output power
- RJ45 cable tracker of digital radar, stronger anti-jamming ability
- Auto OTDR, expert OTDR, event map, OPM, LS, VFL, RJ45 cable tracker, RJ45 cable sequence, RJ45 cable length, end face detection, flashlight optical loss test
- RJ45 cable sequence /cable length test, up to 300m
- One clicks screen capture, easy to save the interface
Technical Specifications
| Wavelength | 1310/1550 ±20nm |
| Use | FTTH |
| Wavelength | 1310/1550 nm |
| Interface | SC and FC two port |
| Distance | 100km |
| Available Wavelength | Single wavelength 1550nm |
| Test Distance | 60-80KM |
| Fiber Type | Single mode |
| Wavelength | 1310/1550 ±20nm |
| Loss Resolution | 0.001dB |
| Loss Threshold | 0.20dB |
| Range Resolution | 0.001m |
| Refractive Index | 1.00000 to 2.00000 |
| Reflection Accuracy | ±3dB |
| Loss Analysis | 4-point method, 5-point method |
| Refresh Rate | 3Hz (Typical) |
| Network | Wifi 4G, 3G |
