Features
• Support Ethernet PoE power supply
• Support LTE Cat 4 network connection
• Support the latest OpenWRT kernel
• Support access to multiple network server platforms
Technical Specifications
| Chipset | SX1302+2 x SX1250 |
| Channel | 8 |
| RX Sensitivity | -139 dBm, 125 KHz / SF12 |
| TX Power | 27 dBm (Max) |
| Frequency | EU433 / CN470 / EU868 / US915 / AS923 / AU915/ IN865 / KR920/RU864 |
| Frequency | 2.4 GHz (802.11b/g/n) |
| RX Sensitivity | -95 dBm (Min) |
| TX Power | 20 dBm (Max) |
| Operation Channels | 2.4 GHz: 1 to 13 |
| LTE Cat 4 Network Connection | Support Quectel EC25-E/EC25-AFXD/EC200M-CN |
| Access To Multiple Network Server Platforms | TTN, AWS, Chirp Stack |
| Power | 12 V DC |
| POE Backup UPS | (IEEE 802.3 af), 40 to 57 V DC |
| Ethernet | RJ45 (10 M / 100 M) |
| Dimension | 6.69 in x 4.72 in x 1.97 in (17 cm x 12 cm x 5 cm) |
| Weight | 12.6 Oz (350 g) |
