| Logger Mode | GPRS and Ethernet (Wi-Fi option available) |
| Customized Logger Interval | Yes |
| History Record Query & Export | Yes |
| Cloud/Local Server Support | Supports up to 4 cloud or local servers |
| Real-Time Monitoring on Cloud | Web-based multi-display modes for T&H (Temperature & Humidity) |
| T&H Graph & List Support | Yes |
| Multi-Point Monitoring | Yes |
| Device Status Display | Real-time status: online, offline, alarm |
| Google Map Track | Yes |
| T&H Alarm | Custom low/high alarm levels, web notifications (icon, sound), SMS, email, local device alarm (optional) |
| T&H Control | Programmable local output control, SMS remote control, web interface control, 32 channels via RS485 |
| Digital Inputs | 4 digital inputs for alarm signals |
| Analog Inputs | 8 analog inputs (for voltage, current, level sensors) |
| RS232 for Configuration | Yes |
| Data Logger | Cloud Data Logger with customizable intervals |
| Wireless Network | GPRS (with 3G/4G option), Wi-Fi (no SIM card required) |
| Ethernet | Supports ARP, DHCP, TCP, UDP protocols |
| SMS Features | SMS alarms, editable SMS texts, SMS report, power failure SMS, query SIM balance, remote config via SMS |
| Technical Features | Auto reconnect & retransmission, inside watchdog, optional battery (8-20 hours), GPS module |
| CWT5018 MCU | Cortex M3 32-bit ARM |
| Power Supply | 9-28V DC (Standard adapter: DC 12V/1.5A) |
| Power Consumption | 12V input Max. 150mA / Average 50mA |
| Wireless Network | GPRS/3G/4G (SIM card required) or Wi-Fi (no SIM card required), GSM/GPRS (4 bands) |
| Wi-Fi | 802.11 b/g security WEP/WPA/WPA2 |
| Ethernet Communication Rate | 10/100M |
| GPS Module | Optional |
| SIM/UIM | Standard user card interface |
| Terminals | 2×14 pin 0.150 in(0.381 cm)spacing, pluggable |
| Battery | Lithium-polymer, 500mAh/3.7V, 8-20 hours life |
| Housing | IP30 protection |
| Antenna | Standard SMA female interface (50Ω) |
| Working Humidity | Relative humidity 95% |
| Working Temperature | -22°F to 158°F (-30℃ to +70℃) |
| Weight | 13.76 oz (390g) |
| Dimension | 5.12 in × 3.15 in × 0.98 in (13 cm × 8 cm × 2.5 cm) |
