Multi Function Power Meter with Visual Fault Locator – The Inventory Master

Name: Multi Function Power Meter with Visual Fault Locator – The Inventory Master - The Inventory Master
SKU: TIMTDRT-248

Versatile fiber optic tester with multiple functions, including OTDR, OPM, VFL, and OLS, for efficient network analysis and maintenance.

SKU: TIMTDRT-248 Category: Industrial Ethernet

Features

Wavelength	1310/1550nm
Dynamic Range	22 dB to 20 dB
Attenuation Dead Zone	22.97 ft (7.0 m)
Event Dead Zone	3.28 ft (1.0 m)
Distance Setting	Max 49.71 mi (80 km)
Connector	FC/UPC interchangeable adapter or customize
Pulse Width	5 ns to 20 μs
OPM Function	+26 dBm to -50dBm, 850/1300/1310/1490/1550/1625nm, 2.5mm UPP
VFL Function	10 mW, 2.5 mm universal connector
OLS Function	Same wavelength and connector as OTDR
Storage	Internal memory or TF card (optional)
Power & Data Port	TYPE-C
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Dimension	6.3 in x 3.3 in x 1.5 in (16 cm x 8.5 cm x 3.8 cm)
Weight	About 15.1 oz (430 g)
