Features
- Ultra-short dead zone
- Visible laser detection
- Intelligent fault analysis
- USB file transfer
Technical Specifications
| Optical Fiber Type | Single-Mode |
| Central Wavelength | 1310 nm to 1550 nm |
| Dynamic Range | 32 dB to 30 dB |
| Event Dead Zone | 3.3 ft (1 m) |
| Attenuation Dead Zone | 19.7 ft (6 m) |
| Optical Interface | FC/PC (Replaceable: SC, ST) |
| Test Range | 1,640 ft to 524,934 ft (500 m to 160 km) |
| Pulse Width | 5 ns to 20,000 ns |
| Ranging Accuracy | ±(2.46 ft + Sampling Interval + 0.005% × Test Distance) |
| Attenuation Measurement | ±0.05 dB |
| Reflection Measurement | ±3 dB |
| Data Storage Capacity | ≥2000 Readings |
| Communication Interface | USB, Mini-USB, Ethernet (10M/100M) |
| VFL Output Power | ≥5 mW |
| Dimensions | 8.9 in × 6.3 in × 2.8 in (22.7 cm × 16.0 cm × 7.0 cm) |
| Weight | ≤2.43 lbs (1.1 kg) |
| Operating Temperature | 23°F to 122°F (-5°C to 50°C) |
