Features
- Multi-wavelength testing
- Built-in Visual Fault Locator
- Long testing range
- High-capacity battery
Technical Specifications
| Usage | FTTH |
| Network | Wireless LAN, Wired LAN, POE, WiFi, GSM |
| Connector Type | SC, FC APC/SC UPC |
| VFL Wavelength | 650 nm |
| Testing Range | 0.62 mi to 0.62 mi (1 km to 256 km) |
| Power Management | Smart power-saving management, over 20 hours of battery life |
| Impact Resistance | Drop-tested from 4.92 ft (1.5 m) |
| Water Resistance | Waterproof and splash-resistant |
| OPM Wavelength Range | 800 to 1700 nm |
| Battery | 1 lithium-ion battery required (included) |
| Color | blue |
| Fiber Type | 9/125 µm |
| Case Capacity | Up to 6561.68 ft (2000 m) of fiber |
| Applications | GPON, FTTX, EPON |
| Operating Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Dimensions | 9.96 in x 6.61 in x 2.9 in (25.3 cm x 16.8 cm x 7.36 cm) |
| Weight | 1.1 lb (0.5 kg) |
