Features
- Double Injection Case
- Impact Resistance
- Protection from Dust
- High Current Loop Test
Technical Specifications
| Color | Blue or Gray |
| Brand | CEM |
| Usage | Test Insulation Resistance |
| Application | Industrial |
| Display | 3.5 in TFT color LCD display |
| Display Type | Digital Only |
| Terminal Voltage | 125 V, 250 V, 500 V, 1000 V |
| Measuring Range | 4000 MΩ |
| Testing Voltage | 1000 V |
| Accuracy Class | ± (2%+10) |
| Range | 0.125 MΩ to 4000 MΩ 0.250 MΩ to 4000 MΩ 0.500 MΩ to 4000 MΩ 1.000 MΩ to 4000 MΩ |
| Low OHM | 4.000Ω 40.00Ω 400.0Ω |
| Operating Temperature | 32 ℉ to 113 ℉ (0 C to 45 C) |
| Dimensions (H x W x D) | 8.66 in x 3.79 in x 2.38 in (22 cm x 9.65 cm x 6.05 cm) |
