Features
- High-precision measurements
- Wide dynamic range
- User-friendly touchscreen
- Long-distance testing
Technical Specifications
| Working Wavelength | Single Mode: 1310/1550/1625/1650 ±20 nm |
| Max Dynamic Range | 28 dB; Tests Fiber Optic Lines Up to 100 km |
| Event Dead Zone | 6.56 ft (2 m) |
| Attenuation Dead Zone | 26.25 ft (8 m) |
| Display | 7 in TFT Color LCD (Capacitive Touch Screen) |
| Battery | Standby Time ≥6 h |
| Output Port | FC/UPC (Standard; SC/UPC Optional) |
| Interface | USB Type C, Micro SD |
| Memory | 32 GB TF Card (Pre-Installed With Analysis Software) |
| Power Adapter | AC/DC Adapter: Input: AC 100 V to 240 V, 50/60 Hz; Output: DC 5 V/2 A |
| Distance Accuracy | ±(0.75 m + Measuring Distance × 0.0025% + Sampling Resolution (Excluding Refractive Index Error) |
| Max Sampling Points | 256 k |
| Linearity | 0.03 dB/dB |
| Loss Resolution | 0.001 dB |
| Operating Temperature | 32°F to 104°F (0°C to 40°C)(Battery Charging: 41°F to 104°F (5°C to 40°C)) |
| Dimension | 7.87 in × 6.10 in × 1.50 in (20 cm × 15.5 cm × 3.8 cm) (Excluding Rubber Bumper) |
| Weight | Approximately 1.54 lbs (0.7 kg) (with Battery) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C)(Battery Charging: 41°F to 104°F (5°C to 40°C)) |
