Features
- Compact, portable design
- High-definition touch screen
- Multi-functional testing capabilities
- Long battery life
Technical Specifications
| Visual Fault Locator (VFL) | 10 mW; 2.5 mm universal connector |
| Display | 3.5-inch high-definition touchscreen |
| Self-Calibration Function | Supported |
| Measurement Modes | Real-time, average, automatic |
| Dynamic Range | 20 dB |
| Test Range | 328 ft to 49.7 mi (100 m to 80 km) |
| Wavelength | 1550 nm (±20 nm) |
| OTDR/OLS Connector | SC/UPC |
| Pulse Width | 5 ns to 20 µs |
| Attenuation Dead Zone | 39.4 ft (12 m) |
| Event Dead Zone | <8.2 ft (<2.5 m) |
| Sampling Points | 20,000 |
| Relative Humidity | <90% |
| Operating Temperature | 32°F to 122 °F (0°C to 50°C) |
| Storage Temperature | -4°F to 158 °F (-20°C to 70°C) |
| Dimensions (H x W x D) | 4.96 in x 3.15 in x 1.46 in (12.6 cm x 8 cm x 3.7 cm) |
| Weight | 7.05 oz (200 g) |
