Features
- Precise measurements
- Portable design
- Intuitive interface
- Fast data processing
Technical Specifications
| Dynamic Range | 24 dB |
| Event Dead Zone | 8.2 ft (2.5 cm) |
| Attenuation Dead Zone | 26.2 ft (8 m) |
| Measurement Range | 1,640 ft to 328,084 ft (500 m to 100 km) |
| Pulse Width | 3 ns to 20 µs |
| Linearity | ±0.05 dB/dB |
| Sampling Points | 16k to 128k |
| Sampling Resolution | 0.16 ft to 26.2 ft (0.05 m to 8 m) |
| Reflection Accuracy | ±3 dB |
| Data Storage | 8 GB |
| Laser Safety Level | Class 2 |
| File Format | Standard SOR Format |
| Optical Connector | FC/UPC (Interchangeable SC, ST); SC/APC Optional |
| Optical Power Meter Wavelength Range | 800 nm to 1700 nm |
| Optical Power Measuring Range | -70 to +6 dBm or G83-50 to +26 dBm |
| Optical Power Meter Uncertainty | ±5% |
| Optical Light Source Laser Type | FP-LD |
| Optical Light Source Output Wavelength | 1550 nm ±20 nm |
| Optical Light Source Adjustable Output Power | -2 dBm to -10 dBm ±2 dB |
| Visual Fault Locator Wavelength | 650 nm ±20 nm |
| Network Cable Function Test Distance | 0 ft to 984 ft (0 m to 300 m) |
| Screen | 4.3-inch Capacitive Touchscreen |
| Scalable External Storage | TF Card |
| Power Supply | Lithium Battery |
| Battery Life | Standby >20 Hours Testing >12 Hours |
| Relative Humidity | 0 % to 95% No Condensation |
| Dimensions | 6.81 in x 4.29 in x 1.77 in (17.3 cm x 10.9 cm x 4.5 cm) |
| Weight | 1.1 lbs (500 g) |
| Operating Temperature | 14°F to 131°F (-10°C to +55°C) |
| Storage Temperature | -40°F to 176°F (-40°C to +80°C) |
