Features
- Portable and user-friendly
- Accurate fault detection
- Optical power measurement
- Fiber network testing
Technical Specifications
| Display | 3.5-inch color LCD |
| Data Interface | Micro USB |
| Battery Life | Standby: >20 h; Testing: >12 h |
| Connector | FC/PC (Interchangeable SC, ST) or FC/APC (Interchangeable SC, ST) |
| Event Dead Zone | 32.8 feet (10 cm) |
| Attenuation Dead Zone | 49.2 feet (15 cm) |
| Testing Range | 32.8 to 196,850 feet (10 to 60 km) |
| Pulse Width | 5 ns to 10 µs |
| Loss Accuracy | ±0.2 dB/dB |
| Sampling Points | 16k to 128k |
| Sampling Resolution | 0.16 to 26.25 feet (0.05 to 8 m) |
| Reflection Accuracy | ±3 dB |
| Data Storage | Internal: 2600 records External: TF card |
| Wavelength Range | 800 to 1700 nm |
| Optical Power Testing Range | -50 to +26 dBm |
| Uncertainty | ±5% |
| Output Power | 2 to 5 dBm |
| Operating Wavelength | 650 nm ±20 nm |
| Operating Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Dimensions | 6.81 in x 3.23 in x 1.46 in (17.3 cm x 8.2 cm x 3.7 cm) |
| Weight | ≤0.77 lbs (≤350 g) |
