Features
- Real-Time Averaging
- Automatic Distance Adjustment
- Zoom Tools for Analysis
- Bidirectional Analysis
Technical Specifications
| Wavelengths (nm) | 1310 ± 20 / 1550 ± 20 / 1625 ± 10 / 1650 ± 5 1625 nm: high pass >1595 nm, isolation >60 dB from 1270 nm to 1585 nm 1650 nm: bandpass 1650 nm ± 7 nm, isolation >60 dB out of 1650 nm ± 10 nm |
| Dynamic Range at 20 µs (dB) | 39 / 38 / 39 / 39 |
| Event Dead Zone | 1.64 ft (0.5 m) |
| Attenuation Dead Zone | 8.2 ft (2.5 m) |
| Distance Range | 328 ft to 248 mi (0.1 km to 400 km) |
| Pulse Width | 3 to 20,000 ns |
| Linearity | ±0.03 dB/dB |
| Loss Threshold | 0.01 dB |
| Loss Resolution | 0.001 dB |
| Sampling Resolution | 0.13 ft to 32.8 ft (0.04 m to 10 m) |
| Sampling Points | Up to 256,000 |
| Distance Uncertainty | ± (2.46 ft + 0.0025% × distance + sampling resolution) |
| Measurement Time | User-defined (maximum: 60 minutes) |
| Typical Real-Time Refresh | 4 Hz |
| Stable Source Output Power | −2.5 dBm |
| Reflectance | ±2 dB |
| Input Power Range | 1490 nm: −65 to 18 dBm 1550 nm: −50 to 28 dBm |
| PON Power Meter | Two channels: 1490 / 1550 nm |
| Broadband Power Meter | One channel: 1270 to 1625 nm |
| Power Uncertainty | ±0.2 dB |
| Calibrated Wavelengths | 1310, 1490, 1550, and 1625 nm |
| PON Power Meter Spectral Band | 1450 nm to 1530 nm |
| Broadband Power Meter Spectral Band | 1270 nm to 1625 nm |
| Display Resolution | 0.1 dB |
| PON Power Meter ORL | −55 dB |
| Broadband Power Meter ORL | −50 dB |
| Temperature | −40°F to 158°F ( −40°C to 70°C) |
| Weight | 14.11 oz (0.4 kg) |
| Size | 6.22 in × 0.94 in × 6.85 in (15.8 cm × 2.4 cm × 17.4 cm) |
