Technical Specifications
| Micro Module Dimensions Single Channel (with aisle containment) | L x 2,200 mm x 2,300 mm / L x 2,200 mm x 2,400 mm / L x 2,400 mm x 2,300 mm / L x 2,400 mm x 2,400 mm / Customized |
| Micro Module Dimensions Double Channel (with aisle containment) | L x 3,200 mm x 2,300 mm / L x 3,200 mm x 2,400 mm / L x 3,600 mm x 2,300 mm / L x 3,600 mm x 2,400 mm / Customized |
| Micro Module Cabinets Per Module | Single channel ≤ 24 cabinets; Dual channel ≤ 48 cabinets |
| Micro Module Power Supply | 208V/380V/400V/415V DC/AC, 50 Hz/60 Hz, 3 Ph + N + PE |
| Micro Module Max IT Load Per Module | 125 kW (with integrated UPS) / 145 kW (with integrated PDC) / 235 kW (with precision PDC) |
| Micro Module Cable Routing | Routed in/out through the top of cabinets |
| Micro Module Installation | Installing on raised floor |
| Cabinet Dimensions (H x W x D) | 2,000 mm x 600/800 mm x 1,200 mm / 2,000 mm x 600/800 mm x 1,100 mm / 2,200 mm x 600/800 mm x 1,200 mm |
| Space Available | 42U/47U |
| Protection Level | IP20 |
| Air Conditioner Installation | In-Row or vertical direction of one end |
| Refrigeration | Direct expansion air cooling, chilled water, and cooling water system |
| In-Row Air Conditioner | Cooling capacity: Optional |
| Dimensions (H x W x D) | 2,000 mm x 300 mm x D / 2,000 mm x 600 mm x D |
| Power Supply | 208V/380V~415V AC, 50 Hz/60 Hz, 3 Ph + N + PE |
| Refrigerant | R410A / R407C |
| Integrated UPS Input Voltage | 208V/380V/400V/415V AC, 50 Hz/60 Hz, 3 Ph + N + PE |
| Input | 250A/400A MCCB |
| Input Power Factor | Full load > 0.99, Half load > 0.98 |
| Output Power Factor | 1 |
| Rated Capacity | 25 kVA~125 kVA |
| Output | IT: 40A/1P x 24 x 2; A/C: 40A or 63A/3P x 8; Lighting: 10A/1P x 3 |
| Efficiency | ≥ 96% |
| Integrated Power Distribution Cabinet (UPS outside) Input Voltage | 380V/400V/415V AC, 50Hz/60Hz, 3 Ph + N + PE |
| Input | IT: 160A/250A MCCB; A/C: 160/250A MCCB |
| Rated Input Current | IT: 160A/250A, A/C: 160A/250A |
| Output | IT: 32A/1P x 2 per cabinet; A/C: 40A or 63A/3P per; Lighting: 10A/1P |
| Precision Power Distribution Cabinet (UPS outside) Input Voltage | 208V/380V/400V/415V AC, 50 Hz/60 Hz, 3 Ph + N + PE |
| Input | 160A/250A/400A MCCB |
| Output | 32A/1P, maximum 144 routes |
| Smart Bus Bar (UPS outside) Input Voltage | 208V/380V/400V/415V AC, 50 Hz/60 Hz, 3 Ph + N + PE |
| Input | 160A/250A MCCB |
| Output | 32A/1P |
