The Inventory Master Android Industrial PDA Android UHF RFID Reader – Frequency 865 MHz To 868 MHz Or 920 MHz To 925 MHz

The Inventory Master Android Industrial PDA Android UHF RFID Reader is an industrial & humanized keypad design and tough 5.5 in (13.9 cm) Gorilla Glass 3 touch screen together with high resolution of 28.3 in X 56.6 in (720 mm X 1440 mm) display shall match high standards in logistics, express and retail industries.

SKU: TIMUHF-941 Category:

Features

  • Industrial and Humanized Hardware Design
  •  Octa-Core Processor & Large Memory
  • Superior Data Communication
  • Rugged Ergonomic and Over-molding Design
  • Extremely Long Distance
  • Perfect Service



Technical Specifications

Frequency865 MHz to 868 MHz or 920 MHz to 925 MHz
ProtocolEPC C1 GEN2 or ISO 18000-6C
R or W range65.6 ft (20 m) (tags and environment dependent)
AntennaCircular antenna (4 dBi)
RFID NFC (Frequency)13.56 MHz
ProtocolISO 14443A & 15693, NFC-IP1, NFC-IP2
R Or W Range0.79 in 1.97 in (20 mm to 50 mm)
Operating SystemAndroid 10.0
CPUCortex A73 2.0 GHz octa-core
RAM2 GB
ROM16 GB
BatteryRechargeable li-ion polymer, 3.8 V, 9000 mAh
DisplayGorilla Glass 3 9H 5.5 in. (13.9 cm) TFT-LCD touch screen with backlight
IP DegreeIP65
BacklightLED backlight
Expansions1 PSAM, 1 SIM, 1 TF
Storage2 GB RAM or 16 GB ROM or 4 GB RAM or 64 GB ROM, MicroSD (max 256 GB expansion)
SDKSoftware Development Kit
LanguageJava
EnvironmentAndroid Studio or Eclipse
WWANTDD-LTE Band 38, 39, 40, 41; FDD-LTE Band 1, 2, 3, 4, 7, 17, 20;
WCDMA (850 MHz or 1900 MHz or 2100 MHz);
GSM or GPRS or Edge (850 MHz or 900 MHz or 1800 MHZ or 1900 MHz)
WLAN2.4 GHz or 5.0 GHz Dual Frequency, IEEE 802.11 a/b/g/n/ac
WPANBluetooth Class v2.1 + EDR, Bluetooth v3.0 + HS, Bluetooth v4.2
GPSGPS (embedded A-GPS), accuracy of (5 m)
2D CMOS Imager (2D Barcode)Zebra SE4710 or Mindeo ME5600
SymbologiesPDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR
Code, Aztec, MaxiCode, Postal Codes, US PostNet, US Planet, UK Postal,
Australian Postal, Japan Postal, Dutch Postal. etc.
ResolutionRear 13 megapixel, front 5.0 megapixel
LensAuto-focus with LED flash
Standard1 x Power Supply; 1 x Lithium Polymer Battery; 1 x Type-C cable
OptionalCradle
Drop Specification5ft. (1.5 m) drop to concrete across the operating temperature range
SealingIP65, IEC compliance
ESD± 15 kv air discharge, ± 8 kv direct discharge
Humidity5 % RH to 95 % RH (non-condensing)
Operating Temperature  -4 °F to 122 °F (-20 °C to 50 °C)
Storage Temperature  -68 °F to 158 °F (20 °C to +70 °C)
Dimensions6.5 in X 3.1 in X 1.2 in (166 mm X 79 mm X 31 mm)
Weight21.1 oz (600 g)
