Technical Specifications
| Frequency Range | 840MHz to 960MHz, adjustable |
| Protocol | EPC C1G2, ISO18000-6B or C |
| Frequency Band | GB 920MHz to 925MHz, 840MHz to 845MHz; FCC 902MHz to 928MHz; |
| Optional Frequency Band | ETSI865MHz to 868MHz; JP 916.8MHz to 920.4MHz; TW922.25 MHz to 927.75MHz; ID923.125 MHz to 925.125MHz; RUS, 866.6 MHzto 867.4 MHz; TEST, 802.75 MHz to 998.75MHz; JP_LBT,916.8 MHz to 920.8MHz |
| Communication Protocol | TCP or IP |
| Reading Distance | 0ft to 65.617ft(0 m to 20 m), adjustable |
| Antenna Port | 4 TNC ports |
| I or O Interface | 2 inputs, 3 outputs |
| Working Mode | Fixed frequency or frequency hopping optional |
| RF Output Power (port) | 33dBm±1dBm(MAX) |
| Recognizing Speed | >600 times to S |
| Communication | COM port or network |
| RS232 | Baud rate support 9600, 19200, 115200 (default), 460800 optional |
| Power Supply | 12V or 3A |
| Power Consumption | 20W (output power 33dbm) |
| Certification | CE FCC ROHS |
| Developing Support | C#, JAVA, Android |
| Installation Method | Fixed by four screw holes |
| Material | Aluminum |
| Working Humidity | <95% 77°F (+25°C) |
| Operating Temperature | -4 °F to 140 °F. (-20 ºC to +60 ºC) |
| Storage Temperature | -40 °F to 185 °F (-40℃ to +85℃) |
| Dimension | 7.6in X0.7inx1.0in (195.4 mm x154.4 mmx27mm) |
| Net Weight | 2.64lbs(1.2kg) |
