Technical Specifications
| Working Frequency | ISM 902 MHz to 928 MHz and ISM 865 MHz to 868 MHz, Other frequency standards (customized) |
| Supported Protocols | ISO18000-63:2015, EPC GEN2 |
| Operation Mode | Fixed Frequency or Software Programmable |
| RF Power | 0 dBm to 33 dBm, Software Programmable |
| Reading Speed | Single card average reading is 64 bits, less than 6 ms, Software Programmable |
| Work Mode | reading Active and reading passive, Software Programmable |
| Communication Ports | E: Wiegand26/34/98, RS232, TCP, USB |
| Maximum Effective Radiated Power | 0 dBm to 33 dBm, which can be adjusted by software |
| Dust And Water Resistant | IP66 |
| Upgrade Software Onsite | Support updating the firmware |
| Data Transfer Rate Between RFID Reader And RFID Tag | Above 26.7 kbps |
| Read Rate | Up to 100 tag per second |
| Tag Speed | Up to 74.6 miles per hr (120 km per hr) |
| Image Analyzation | Reader support buzzer for specific error, SDK support error code for specific error |
| Driver Or SDK | Provide SDK with VC, C# and other languages |
| Input Interface | One channel input |
| Status Indicators | Buzzer |
| Antenna | 10 dbi circular antenna |
| Power Supply | DC +9 V |
| Operating Humidity | Up to 95 % |
| Reading Range | More than 19.69 ft (6 m) |
| Storage Temperature | -4 °F to 185 °F (-20 ℃ to +85 ℃) |
| Size | 9.45 in x 16.54 in x 2.20 in (240 mm x 420 mm x 56 mm) |
| Weight | 3.42 lbs (1.55 Kg) |
