Features
- Audio and visual alarm
- Customizable width
- Back list setting
Technical Specifications
| Frequency Range | 860 MHz to 960 MHz |
| Protocol | EPC C1G2, ISO18000-6B/C |
| Chip | Impinj R 2000 |
| Communication Protocol | TCP or IP |
| Antenna Port | 4 TNC ports |
| I Or O Interface | 2 inputs 3 outputs |
| Frequency Band | GB 920 MHz to 925 MHz 840 MHz to 845 MHz FCC 902 MHz to 928 MHz |
| Optional Frequency Band | ETSI 865 MHz to 868 MHz JP 916.8 MHz to 920.4 MHz TW 922.25 MHz to 927.75 MHz ID 923.125 MHz to 925.125 MHz RUS 866.6 MHz to 867.4 MHz TEST 802.75 MHz to 998.75 MHz JP LBT 916.8 MHz to 920.8 MHz |
| Working Mode | Fixed frequency or frequency hopping optional |
| RF Output Power (Port) | 33 dBm ± 1dBm (MAX) |
| Recognizing Speed | > 600 times per sec |
| Communication | COM port or network |
| RS232 | Baud rate support 9600 19200 115200 (default) 460800 optional |
| Screen | 10.1 touch screen (optional) |
| Screen Ratio | 16:9 |
| Installation Method | Fixed on the floor |
| OS | Windows (optional for Android) |
| Screen | 10.1 touch screen(optional) |
| Mini PC | N29 2G RAM 32 GROM (RK3399 2 G +8 G) |
| Power Supply | 220 V 10 A 50 Hz |
| Power Consumption | 120 W (output power 33 dbm) |
| Reading Distance | 0 ft to 65.62 ft (0 m to 20 m) |
| Working Humidity | < 95 % |
| Operating Temperature | – 4 °F to 140 °F (- 20 ºC to 60 ºC) |
| Storage Temperature | – 40 °F to 185 °F (- 40 ℃ to 85 ℃) |
| Dimension | 58.86 in x 17.72 in x 7.09 in (1495mm x 450 mm x 180 mm) |
| Net Weight | 110.23 lb (50 kg) |
