| Operating Frequency | 860 MHz to 960 MHz or 902 MHz to 928 MHz or 865 MHz to 868 MHz |
| Support Protocol | ISO18000-6C (EPC Gen2) |
| Working Voltage | DC +9 V to 24 V, 12 W |
| Antenna Specifications | 8dBi circularly polarized Antenna |
| Card Type | ISO18000-6C (EPC Gen2) UHF Card |
| Card Reading Speed | 400 times per second |
| Communication Ports | RS232, RS485, WG26, WG34, Trigger, Relay (Optional), RJ45 (Optional), WIFI (Optional), POE (Optional), USB (Optional) |
| Net | RJ45 supports TCP Client per Server, Modbus, DNS, DHCP. WIFI supports TCP Client. 4G supports TCP Client. HTTP Protocol (Optional), MQTT(Optional), LLRP(Optional) |
| Reading Prompt | Buzzer |
| Work Mode | Active mode, Answer mode, Trigger mode, Password mode |
| Waterproof | IP65 |
| Output Power | 0 dBm to 26 dBm |
| SDK | Support X86 & X64, C++, C#, VB, Delphi, Linux, ARM, Python, NodeJS, QT, JAVA, Android. |
| Application | Car Parking System, Logistics & Warehouse Management, Library Management etc |
| Reading Range | 0 ft to 26.25 ft (0 m to 8 m) |
| Working Temperature | 68 °F to 140 °F (20 °C to +60 °C) |
| Storage Temperature | -40 °F to 176 °F (-40 °C to +80 °C) |
| Product Size | 7.48 in x 7.48 in x 1.97 in (190 mm x 190 mm x 50 mm) |
