Features
- Scalable processors
- Rack server to address application performance
- Delivers outstanding performance
- Supports 8 channels of memory per CPU
- Address substantial throughput improvements
Technical Specifications
| System Architecture | X86 Server |
| Processor | Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor |
| Memory | 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max Supports registered ECC DDR4 DIMMs only |
| Storage Controllers | Internal controllers: PERC H745, HBA355I, S150, H345, H755, H755N Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB External PERC (RAID): PERC H840, HBA355E |
| Drive Bays | Front bays: Up to 12 x 3.5-inch SAS or SATA (HDD or SSD) max 192 TB Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB Up to 16 x 2.5-inch SAS or SATA or NVMe (HDD or SSD) max 245.76 TB Up to 24 x 2.5-inch SAS or SATA or NVMe (HDD or SSD) max 368.84 TB Rear bays: Up to 2 x 2.5-inch SASor SATA or NVMe (HDD or SSD) max 30.72 TB Up to 4 x 2.5-inch SAS or SATA or NVMe (HDD or SSD) max 61.44 TB |
| Power Supplies | 800 W Platinum AC or 240 HVDC 1100 W Titanium AC or 240 HVDC 1400 W Platinum AC or 240 HVDC 2400 W Platinum AC or 240 HVDC |
| Cooling Options | Air cooling, optional processor liquid cooling |
| Processor Main Frequency | 2.4 GHz |
| Fans | Standard fan or High-performance SLVR fan or High-performance GOLD fan Up to six hot plug fans |
| Dimensions | 3.41 in x 18.97 in x 29.85 in (86.8 mm x 482 mm x 758.3 mm) |
| Form Factor | 2U rack server |
| Server Type | Rack |
| Embedded NIC | 2 x 1 GbE LOM |
| GPU Options | Up to two double-width 300 W, or four single-width 150 W, or six single-width 75 W accelerators |
| Hard Disk Capacity | 12 3.5 in Hard Disk Drive Bits |
| Ports | Front Port 1 x Dedicated iDRAC Direct micro-USB 1 x USB 2.0 1 x VGARear Ports 1 x USB 2.0 1 x Serial (optional) 1 x USB 3.0 2 x RJ-45 1 x VGA (optional for liquid cooling configuration) Internal Ports 1 x USB 3.0 |
| PCIe | Up to 8 x PCIe Gen4 slots (up to 6 x16) with support for SNAP I/O modules |
| Supporting Memory Capacity | 16 GB |
| Workstation Type | Desktop Workstation |
| Platform | PC Workstation |
| Specification | 60 lb (20 kg) |
