Features
- Low power, 10-year lithium battery
- Ultra-high range ratio, 400:1
- Multichannel, more accurate measurement
- Forward and reverse measurement
- 4 high-speed measurements per second
- Horizontal or vertical installation
- Self-diagnosis and alarm functions
Technical Specifications
| Type | Ultrasonic Meters, Prepaid Water Meters |
| Customized Support | OEM, ODM, OBM |
| Material | Cast Iron |
| Accuracy Class | Class 1, Class 2 |
| Pressure Rating | Pressure Rating |
| Communication Mode | RS485, M-BUS, Pulse, Lora, GPRS, GSM, NB-Iot |
| Flow Field Sensitivity | U5 Or D3 |
| Data Storage | 24-Month Historical Data, Alarm Time And Alarm Source |
| Iot Networking | NB-Iot, Complete Set Of The Operation And Management System Platform |
| Installation Mode | Horizontal Or Vertical |
| Range Ratio | Default R250 (R125 Or R160 Or R200 Or R400, It Can Be Customized Made) |
| Pressure Rating | MAP16 |
| Environmental Class | Class B (Class O Is Optional) |
| Max Pressure Loss | ≤1.45 Psi(≤0.01 Mpa) |
| EME Class | E1 |
| Pipe Segment Material | Cast Steel |
| Local Communication | Infrared Meter Reading Interface (M-BUS 485 Optional |
| Protection Class | IP68 |
| Temperature | T30 Or T50 |
