Features
- 2 GHz Quad-Core CPU
- 32 GB plus 2 GB LPDDR 4
- Silent Cooling Fan, Efficient Heat Dissipation
Technical Specifications
| LAN, WAN Port | One 2.5 G ethernet port (RJ 45 waterproof joint), self-adaption MDI, MDIX |
| LAN Port | One 1 G ethernet port (RJ 45 waterproof joint), self-adaption MDI, MDIX |
| Phone Interface (Optional) | One RJ 11 port |
| Indicator Light | Signal, 5G, 4G, WIFI, and Power indicator light |
| SIM, UIM Card | Three-core DC locomotive power socket, built-in power reverse protection |
| USB Port | Type C 2.0 |
| WIFI Protocol | Support IEEE 802.11 a, b, g, n, ac, ax |
| WIFI Frequency Band | 2.4 GHz and 5 GHz |
| Theoretical Bandwidth | 2.4 GHz 4 x 4 MIMO 11 ax, 1.2 Gbps 5 GHz 4 x 4 MIMO 11 ax, 3.6 Gbps5G Sub-6 Downlink 4.67 Gbps, uplink 1.25 GbpsLTE Cat20 Downlink 1.6 Gbps, uplink 150 Mbps |
| Frequency Bandwidth | Standard 5G Sub-6 n 1, 3, 5, 7, 8, 20, 28 (a & b), 38, 40, 41, 77, 78, 79 LTE B 1, 3, 5, 7, 8, 18, 19, 20, 26, 28 (a & b), 30, 38, 40, 41, 42, 43, 46 WCDMA B1, 5, 8Optional 5G NR n 2, 5, 7, 12, 14, 25, 30, 41, 48, 66, 71, 77, 78LTE B 2, 4, 5, 7, 12, 13, 14, 17, 25, 26, 29, 30, 41, 46, 48, 66, 71 WCDMA B 2, 4, 5 |
