Overview
Experience top-tier performance with our device featuring a Rockchip RK3568 Quad-Core CPU, 2GB RAM, 16GB storage, and UHF RFID capabilities.
Technical Specifications
| Color | Silver |
| Processor Platform | |
| CPU | Rockchip RK3568 Quad-Core 64-bit Cortex-A55 Processor Clock speed: 2.0 GHz |
| Storage | Standard configuration includes 2GB RAM and 16GB eMMC |
| UHF Technical Parameter | |
| Air Protocol | 920 MHz to 925 MHz, ETSI, 865 MHz to 868 MHz, FCC, 902 MHz to 928 MHz (default), full channel |
| Features | Support dense read and write, multi-label recognition, label data filtering, support RSSI, perceive signal strength |
| Working Frequency | 920 MHz to 925 MHz, ETSI, 865 MHz to 868 MHz (optional) GB, 840 MHz to 845 MHz (optional), FCC, 902 MHz to 928 MHz (optional) |
| RF Output Power | 33 dBm ±1dB (MAX) |
| Output Power Adjustment | 1 db step walking |
| Antenna Specification | 8 SMA antenna interface |
| Display Specification | HDMI interface |
| Consecutive Label Distance (Reading EPC Code) | 0 ft to 32.8 ft (0 m to 10 m) (related to the performance of the tag chip), using a 9 dBi antenna, with a read success rate of greater than 95 % in a non-interfering environment |
| Continuous Writing Tag Distance (Write EPC Code) | 0 ft to 16.4 ft (0 m to 5 m) (related to the performance of the tag chip), using a 9 dBi antenna, with a read success rate of greater than 90 % in a non-interfering environment |
| External Communication Interface | HDMI/Type-C/USB/RJ-45/RS-232/RS-485/Wiegand/WIFI/BT/4Ginterface and other user interfaces |
| Working Environment | |
| Operating Voltage | DC 12 V or 2 A (DC 9 V to 30 V, 24 W) or POE (IEEE 802.3 af/at/bt) |
| Operating Temperature | -4 °F to 158 °F (-20 ℃ to +70 ℃) |
| Storage Temperature | -40 °F to 185 °F (-40 ℃ to +85 ℃) |
| Working Humidity | 10 % to 95 % Rh without condensation |
| Physical Parameters | |
| Size | 8.4 in x 4.9 in x 1.4 in (213.5 mm × 125 mm × 37.5 mm) |
| Weight | 2.8 lb (1.3 kg) |
