Features
- Color TFT LED display
- Dual operation interface
- Multi-waveform viewing
- Stable light source
Technical Specifications
| Event Dead Zone | 3.3 ft (1 m) / 2.6 ft (0.8 m) |
| Attenuation Dead Zone | 19.7 ft (6 m) |
| Test Range | Up to 158.4 miles (256 km) |
| Pulse Width | 3ns to 20000 ns |
| Ranging Accuracy | ± (2.5 ft (0.75 m) + Sample interval + 0.005% × Test distance) |
| Loss Accuracy | ±0.05 dB/dB |
| Sample Points | 16k to 256k |
| Sample Resolution | 0.2 ft in to 52.5 ft (0.05 m to 16 m) |
| Reflection Accuracy | ±3dB |
| File Format | SOR Standard file format |
| Loss Analysis | 4-point method / 5-point method |
| Refresh Rate | 3Hz (Typ.) |
| Data Storage | Internal: ≤3000 curves; External: 4G bit |
| Connector | FC/UPC (interchangeable SC, ST) |
| Data Interface | USB, Mini-USB, 10M/100M Ethernet Port |
| OPM Wavelength Range | 800 nm to 1700 nm |
| OPM Connector | Universal FC/SC/ST |
| OPM Test Scope | -50 dBm to +26dBm |
| OPM Uncertainty | ±5% |
| LS Wavelength | Consistent with OTDR output wavelength |
| LS Output Power | ≥ -5 dBm |
| LS Stability | CW, ±0.5dB/15min (test after 15 minutes of preheating) |
| LS Connector | FC/UPC (interchangeable SC, ST) |
| VFL Wavelength | 650nm ± 20nm |
| VFL Output Power | > 10mW |
| VFL Mode | CW/1Hz/2Hz |
| VFL Connector | FC/UPC (interchangeable SC, ST) |
| Display | 5.6 inch color LCD + touch screen |
| Relative Humidity | 0% to 95%, Non condensing |
| Working Temperature | 14 °F to 122°F (-10 °C to +50 °C) |
| Storage Temperature | -40 °F to 158°F (-40 °C to +70 °C) |
| Weight | 2.6 lbs (1.2kg) |
| Size (HWD) | 8.9 in x 6.3 in x 2.8 in (22.7 cm x 16 cm x 7 cm) |
