Technical Specifications
| Frequency Range | 840 MHz to 960 MHz, adjustable |
| Protocol | EPC C1G2, ISO18000-6B/C |
| Chip | Impinj R2000 |
| Frequency Band | GB 920 MHz to 925 MHz, 840 MHz to 845 MHz; FCC 902 MHz to928 MHz |
| Optional Frequency Band | Please tell our sales which band you want before ordering: ETSI865 MHz to 868 MHz; JP 916.8 MHz to 920 MHz; TW 922.25 to 927.75 MHz |
| Communication Protocol | TCP or IP |
| Functions | RFID read & write or visible and audible alarm or infrared sensor or incoming or outgoing record or People Counting |
| Antenna Port | 4 TNC ports |
| I / O Interface | 2 inputs, 3 outputs |
| Working Mode | Fixed frequency or frequency hopping optional |
| RF Output Power (Port) | 33 dBm ±1 dBm (MAX) |
| Recognizing Speed | >600 times per S |
| Communication | COM port or network |
| RS232 | Baud rate support 9600, 19200, 115200 (default), 460800 optional |
| Dimension | 5.86 in x 17.7 in x 7.08 in (1495 mm x 450 mm x 180 mm) |
| Screen | 10.1 touch screen (optional, not standard) |
| Resolution | 1366 x 788 |
| Screen Ratio | 16:9 |
| Net Weight | 110.23 lb. (50 kg) |
| Material | Aluminium and Acrylic |
| Installation Method | Fixed on the floor. Contact our sales for installing guide or check the introduction video |
| OS | Windows (optional for Android) |
| Screen | 10.1 touch screen(optional) |
| Mini PC | N29,2 G RAM ,32 G ROM (RK3399, 2 G + 8 G) |
| Power Supply | 220 V, 10 A, 50 Hz |
| Power Consumption | 120 W (output power 33dbm) |
