Features
- MT7628 CPU
- SX1302 chipset
- Wi-Fi enabled
- LTE network
- Ethernet port
Technical Specifications
| Processor | MT7628, DDR2 RAM 128 MB |
| Connectivity | Wi-Fi, LTE, Ethernet |
| LoRaWAN Protocol | V1.0.3, Class A or C |
| Chipset | Semtech SX1302 + 2 x SX1250 |
| Channel | 8 |
| RX Sensitivity (LoRa) | -139 dBm @ 125 KHz or SF12 |
| TX Power (LoRa) | 27 dBm (Max) |
| Frequency (LoRa) | EU433, CN470, EU868, US915, AS923, AU915, IN865, KR920, RU864 |
| Frequency (Wi-Fi) | 2.4 GHz (802.11b or g or n) |
| RX Sensitivity (Wi-Fi) | -95 dBm (Min) |
| TX Power (Wi-Fi) | 20 dBm (Max) |
| Operation Channels (Wi-Fi) | 2.4 GHz: 1 to 13 |
| Ethernet | RJ45 (10M or 100M) |
| Dimension | 6.65 in x 4.72 in x 1.77 in (16.9 cm x 12 cm x 4.5 cm) |
| Weight | 0.77 lb (0.35 kg) |
