Features
- Multi-tags read rate > 200 tags per second
- OS: Android 10.0
- Reading Distance is (0 m to 20 m)
Technical Specifications
| Frequency | 865 MHz to 868 MHz or 902 MHz to 928 MHz |
| Protocol | EPC G2 or ISO 18000-6C |
| Operating System | Android 10.0 |
| Battery Capacity | 3.8 V 9000 mAh |
| Interface | USB |
| Drop | 1 M |
| CPU | Cortex A73 2.0GHz octa-core |
| RAM | 2 GB or 4 GB |
| ROM | 16 GB or 64 GB |
| Camera | Rear 13 MP AF, high light LED flash, Front 5 MP camera |
| Screen | Gorilla Glass 3 9H 5.5 in (13.9 cm) TFT-LCD |
| Battery Capacity | 3.8 V 9000 mAh Li-ion battery, removeable and rechargeable |
| Charging | PE fast charge, full charged time <2 hrs |
| Bluetooth | BT4.2 BLE |
| WIFI | IEEE 802.11 a/b/g/n/ac 2.4G 5G dual frequency |
| GPS | GPS (embedded A-GPS), accuracy of (5 m) 16.4 ft |
| Extension | Micro SD (TF) card slot up to 256 GB |
| External Interface | USB-Type C, other slots: 1 PSAM, 1 SIM, 1 TF |
| Keypad | Volume button, power button, grip button, function button, home button, return button |
| Notification | Sound, Vibration, LED prompt |
| Antenna | Circular antenna (3 dBi) |
| Power | Working voltage 3.6 V to 5 V, RF output 5 dBm to 33 dbm |
| Reading Distance | 0 ft to 65.6 ft (0 m to 20 m) |
| Multi-Tags Read Rate | > 200 tags per second |
| Accessories | 1 x Power Supply; 1 x Lithium Polymer Battery；1 x Type-C cable |
| Drop And Tumble | 6 sides multiple drops from the height of 3.2 ft (1 m) to the concrete floor |
| ESD | ±15 kV air discharge，±8 kV contact discharge |
| Working Humidity | 5 % RH to 95 % RH (non-condensing) |
| Interfaces | USB 2.0 Type-C, OTG |
| RFID (HF) | 13.56 MHz, ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2 NFC Reading distance: 0 in to 3.1 in (0 cm to 8 cm) |
| RFID (UHF) | Protocol standard: EPC G2/ISO 18000-6C; Working frequency: 915 MHz, 865 MHz (865 MHz to 868 MHz or 902 MHz to 928 MHz) Antenna parameters: Circular antenna (3 dBi) Power: working voltage 3.6 V to 5 V, RF output 5 dBm to 33 dBm Standby power consumption is about 0.25 W, maximum 7.5 W (typical 7 W); Reading distance: 0 ft to 65.6 ft (0 m to 20 m) (depends on environment and tag) Multi-tags read rate > 200 tags per s |
| Barcode Scanning | Zebra SE4710/ Mindeo ME5600/ Others |
| Support Code System | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, Maxi Code, Postal Codes, US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal. Etc. |
| Working Temperature | -4 °F to 122 °F (-20 ℃ to 50 ℃) |
| Storage Temperature | -4 °F to 158 °F (-20 ℃ to 70 ℃) |
| Dimensions | 6.5 in X 3.5 in X 1.2 in (166 mm × 79 mm × 31 mm) |
| Weight | 22.9 oz (650 g) |
