Overview
The Inventory Master high-performance UHF RFID integrated reader is designed based on fully intellectual property. Based on patented efficiency digital signal processing algorithm, supports fast tag read/write operation with high identification rate. It is applied in many RFID application systems, such as logistics, access control, and industrial production processes, and anti-counterfeiting.
Features
- Self-intellectual property
- Support ISO18000-6B, ISO18000-6C (EPC C1G2) protocol tag
- 6 MHz to 868 MHz frequency band
- FHSS or Fix Frequency transmission
- RF output power up to 30 dBm (adjustable)
- 12 dBi antenna optional with effect distance more than 32.8 ft (10 m)
- Support auto-running, interactive, and trigger-activating work mode
- Low power dissipation with a single +9 DC power supply
- Support RS232, RS485, Wiegand interface
- Provide DLL and Demonstration Software Source code
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Standard | EPC C1 GEN2/ISO 18000-6C |
| Read Range | 3.2 ft to 26.2 ft (1 m to 8 m) |
| Output Power | 0 dBm to 30 dBm (Adjustable) |
| Support Chip | Alien H3, M4QT, etc |
| Software | C++/VB/VC/C#/JAVA |
| Applications | -Warehouse Management -Parking lot -Logistics Management -UHF Animal Management |
| Interface | RS232/RS485(TCP/IP upon to custom) |
| Size | 10.03 in x 10.03 in x 2.24 in (255 mm × 255 mm × 57 mm) |
